Lab 7: CPU Design

The purpose of this lab is to go over the CPU design you will implement for the project.

Take a look at the CPU design document. Try writing a program that loads register A with the number 0x00FF, loads register B with the number 0x0001, and then adds register A to register B and puts the result in register C.

(Note, the two characters 0x are often used to denote a hexadecimal number in programming languages.)

Ask questions about the design.

When you feel you understand the design, go ahead and get started on the current project.
