CS 231: Project #7

Trees v. Hashing

The main purpose of this project is to give you the opportunity to examine the efficiency of your Hashmap and your BSTMap when counting words in the Reddit comment files.

Note: please do not hand in the Reddit comment files with your code. If everyone hands them in with their code, it takes up a lot of unnecessary space on the server.

It looks like Java takes at least 4G of memory to put the words into an ArrayList. Use the flag -Xmx4096m when running your program or set the default memory size to at least 4G.

Video: Comparing Data Structures

Tasks

1. Write a WordCounter2 class

   In order to properly compare the times for building a BSTMap versus a Hashmap, we need to separate the file I/O from the process of building the data structure. Your WordCounter2 should have a field of type MapSet to hold the data structure and a field of type int to hold the total word count.

   Write the following methods. Many of them can re-use code from last week.

   1. public WordCounter2( String data_structure ) - constructor, where data_structure is either "bst" or "hashmap". It should create the appropriate data structure and store it in the map field.
   2. public ArrayList<String> readWords( String filename ) - given the filename of a text file, read the text file and return an ArrayList list of all the words in the file.
   3. public double buildMap( ArrayList<String> words ) - given an ArrayList of words, put the words into the map data structure. Return the time taken in ms. Record the time using System.nanoTime().
   4. public void clearMap() - clear the map data structure.
   5. public int totalWordCount() - return the total word count from the last time readWords was called.
   6. public int uniqueWordCount() - return the unique word count, which should be the size of the map data structure.
   7. public int getCount( String word ) - return the number of times the word occurred in the list of words. Query the data structure to get the information. Return 0 if the word does not exist in the data structure.
   8. public double getFrequency( String word ) - return the frequency of the word in the list of words. Query the data structure to get the word count and then divide by the total number of words to get the frequency. Return 0 if the word does not exist in the data structure.
   9. public boolean writeWordCount( String filename ) - write a word count file given the current set of words in the data structure. The first line of the file should contain the total number of words. Each subsequent line should contain a word and its frequency.
   10. public boolean readWordCount( String filename ) - read a word count file given the filename. The function should clear the map and then put all of the words, with their counts, into the map data structure.
2. Robustly calculate the time it takes to build the map

   The WordCounter2 main function should first read the words from the file into an ArrayList using the readWords method. Then it should calculate a robust average of the time it takes to build the map. For example, loop five times, each time through the loop clearing the map and then building the map, storing the run times. Then calculate a robust average by dropping the low and high values and computing the average of the remaining times.

   If you wish, automate the process for all eight of the Reddit files. At the end of the analysis, have your program print out the average run time in ms, the total number of words, and the number of unique words (for each file).

   Remember to clear your MapSet data structure prior to running the buildMap method each time through the loop.

3. Compute statistics for the BSTMap for all of the Reddit files

   Run the analysis using your BSTMap method from last week on all eight Reddit files and record the run-times, total words, total unique words, and the depth of your tree in a spreadsheet or CSV file. Add the file size for each year as a separate column. You can use the Terminal command ls -lh to get the file sizes in human-readable format.

4. Compute statistics for the Hashmap for all of the Reddit files

   Repeat the timing process using the Hashmap data structure. Add the hash map times as another column in your spreadsheet or CSV file. To measure the effectiveness of the hash function (how well it distributed keys), have your hash table version also print the number of collisions.

   A collision occurs when a key is inserted into the hash table for the first time and another key already exists at that hash location.

   Simply updating the value in a key-value pair does not cause a collision. Also, since the goal is to understand how well the hash function distributes the data across the table, reset the collision count to 0 whenever the table size increases. As the key-value pairs are re-inserted into the larger table, increment the collision count appropriately.

5. Plot your results

   Use a spreadsheet program (or python and matplotlib) to report the numbers with an XY scatter plot. Make three plots.

   1. Year versus run-time: the x-axis should be the year, and the y-axis should be the run-time. Show both the BST and Hash map run times.
   2. Total number of words versus run-time: the x-axis should be the total number of words. Show both the BST and Hash map run times.
   3. Unique words versus run-time: the x-axis should be the number of unique words. Show both the BST and Hash map run times.

   Do your plots make sense? (If not, figure out why not and fix your code). If there are any trends, describe them. Which data structure appears to be faster on this data set? Include the graphs in your report. Wny do you think one is faster than the other?

6. Analyze the performance of the BSTMap and Hashmap as data structures

   Analyze the performance of the BSTMap and Hashtable to see how close to ideal they perform using either total words or file size versus run-time. Start by stating what ideal means in terms of big-O notation. For the Hashtable, does the number of collisions affect performance? For the BSTMap, does the depth/height of the tree affect performance? Include this analysis in your report.

7. Experiment with the Hashmap

   Change one aspect of your Hashmap to try and make it faster. For example, change the hash function, change when you expand the table, or change the data structure you are using at each position in the table.

   Analyze the effect of your change on performance. Did it make the Hashmap faster, slower, or have no discernable effect? Does the result make sense?

   Good extensions are to explore more than one modification.

---

Extensions

The following are some suggested extensions. You should feel free to pursue your own custom extensions to your project that you find interesting. Please clearly identify your extensions in your report. In your code, make sure the baseline simulations run properly. Making a separate sub-folder for major extensions is recommended.

1. Test multiple modifications of your Hashmp (not just one) and compare and contrast. Many of the suggested extensions fall in this category.
2. Use additional files to test the (time and/or space) efficiency of your implementations. You want to cover a much bigger range of values (in a logarithmic sense) so you can get an accurate curve.
3. Implement your own hash function. How does its performance compare to the built-in string hash function?
4. Try implementing more than one collision handling method. For example, (1) use whichever (chaining or probing) you haven't implemented yet, or (2) use a BSTMap instead of a linked list at each table entry for chaining. Compare the performance of the methods.
5. Try implementing different probing methods. For example, (1) Linear, Quadratic and Double Hashing. Compare the performance of the methods.
6. Examine the space efficiency of your implementations. One way to do this would be to refrain from using the -Xmx4096m flag. Count words of files of increasing sizes. See what is the size of the smallest size that crashes your program. Does a smaller file crash the Hashtable code or the BSTMap code? Why?
7. Improve the time-efficiency of one of your data structures. Explain what you did and report the improvement in speed.
8. For any assignment, a good extension will be to annotate your code to indicate all places where memory is "lost" (in other words, each place where the last remaining reference to an object is either destroyed or is given a new value). If you do this extension, please indicate so in your report.

---

Report

Your intended audience for your report are your peers not in the class, but who have taken a CS course. Your report should explain the core CS concept used, present the results of your program, and discuss the meaning of the results: what did you discover and does it make sense?

Your project report should contain the following elements. Please include a header for each section.

• Abstract

  A brief summary of the project, in your own words. This should be no more than a few sentences. Give the reader context and identify the key purpose of the assignment. Each assignment will have both a core CS purpose--usually a new data structure--and an application such as a simulation or analysis.

  Writing an effective abstract is an important skill. Consider the following questions while writing it.

  • Does it describe the CS concepts of the project (e.g. writing well-organized and efficient code)?
  • Does it describe the specific project application?
  • Does it describe the data structure you used?
  • Does it describe the results of your simulation or analysis?
  • Is it concise?
  • Are all of the terms well-defined?
  • Does it read logically and in the proper order?
• Results

  Present your results. Include text output, images, tables, graphs, or qualitative descriptions, as appropriate. Include a discussion as to whether the results make sense and what they mean. This week, present your timing results, explain whether they show the correct complexity, and compare the different cases/algorithms.

• Extensions

  Describe any extensions you undertook, including text output, graphs, tables, or images demonstrating those extensions. If you added any modules, functions, or other design components, note their structure and the algorithms you used.

• Reflection

  A brief (1-3 sentences) description of what you learned. Think about the answer to this question in terms of the stated purpose of the project. What are some specific things you had to learn or discover in order to complete the project?

• References/Acknowledgements

  A list of people you worked with, including TAs and instructors. Include in that list anyone whose code you may have seen, such as those of friends who have taken the course in a previous semester.

Handin

Please do not submit the reddit text files along with your code.

Here's a checklist of everything you should do when you are finished with a project and are ready to turn it in.

+ Create a report and export to pdf

+ Zip your project folder

+ Submit your project zip folder and report on Moodle

---
